Fine and light mesh welding machine:
Fine and light mesh welding machine is used to weld live stoke farming mesh with small configuration and small diameter wire, for example for all kinds of cages.
Mesh advance system: drawn by hooks and driven by servo-motor. These special designes escape the possibility of bending the cross wire of the mesh and ensure mesh precision.
Mesh cutting system: the high speed shear cut the endless mesh strip into sheets of any length without slow down the welding machine; automatic cutting, based on the pre-input date by operator.

Fine and light welded wire mesh machine Fine and light welded wire mesh machine Fine and light welded wire mesh machine
Welded wire mesh machine-1 Welded wire mesh machine-2 Welded wire mesh machine-3

Model ABE-PDHW001 ABE-PDHW002
Welding width 12"-60", or designed on demand 12"-60", or designed on demand
Mesh range 1/4"-1", or designed on demand 1"-6", or designed on demand
Wire diameter 0.4-1mm 1.07-2.0mm
Welding Speed >85 (mesh/min) >85 (mesh/min)
Power 380-220V/50-60Hz/3phase 380-220V/50-60Hz/3phase
QTY of main transformer 60KVA*4/60KVA*5 50KVA*6
